Products >> Float Level Switch >> Vertically Install
PP material for Float level switch LS-P0835 with vertical installation applied in tank level auto control system
- Product No.：LS-P0835
www.jsusc.com
Float Level Switch
Specification:
| Model NO. | LS-P0835 |
| Installation | Vertical |
| Switching Type | NO ( Normally Open ) |
| Material | PP |
| Working Temperature | -10~80℃ |
| Wire Gauge | UL 1007 22AWG |
| Wire Length | 300mm |
| Switching Voltage | 110 VDC |
| Switching Current | 0.5A |
| Contact Rating | 10W |
1.Float level switch is widely used in tank level auto control system, startup and shutdown the water pump or electric valve on the basis of liquid level.
2.Vertical installation switch can be mounted on the top or bottom of liquid tank; side installation switch can be mounted on the wall of liquid tank.
3.Switching type definition:
NO: Normally open,mounted switch on the top of tank, switching ON when float rising .
NC: Normally close,mounted switch on the top of tank, switching OFF when float rising.
