Products >> Float Level Switch >> Horizontally install
SUS 304 stainless steel Float level switch LS-SYZ-1 with side installation applied in tank level auto control system
- Product No.：LS-SYZ-1
www.jsusc.com
Float Level Switch
Specification:
| Model NO. | LS-SYZ-1 |
| Installation | Side |
| Switching Type | NO / NC |
| Material | SUS 304 stainless steel |
| Working Temperature | --40~120℃(higher temperature need to be customized) |
| Wire Gauge | UL 3122 22 AWG |
| Wire Length | 300mm |
| Switching Voltage | 110 VDC |
| Switching Current | 0.5A |
| Contact Rating | 10W |
1.Float level switch is widely used in tank level auto control system, startup and shutdown the water pump or electric valve on the basis of liquid level.
2.Vertical installation switch can be mounted on the top or bottom of liquid tank; side installation switch can be mounted on the wall of liquid tank.
3.Switching type definition:
NO: Normally open,mounted switch on the top of tank, switching ON when float rising .
NC: Normally close,mounted switch on the top of tank, switching OFF when float rising.
