Recessed mounted magnetic switch



Ideal for wooden door/ window



Flush mounted magnetic switch

Ideal for wooden door/ window



*Housing: ABS material;fireproof ABS housing is available

*Standard color: white

brown/black color available

*Sensing distance≥15mm, can be customized

*Certificates: CE,FCC,ROHS

*Wires standard length 350mm,longer wires available

*Common out put is NC type,

*Max current:0.5A

*Max voltage:100V

*Max power:10W

*Initial resistance: 200mΩ

2.0 Packaging Details:

Inner packing: 20pcs/bag

Carton:1000pcs/carton

Carton size: 37.5*29.5*30CM

G.W.:16.00KGS

N.W.:15.40KGS

3.0  Drawing(mm)
